Industrial Electronic Analog Timers
Function
Electronic Digital Timers are the latest in line of up-dated instruments,designed to match modern sophisticated time control equipments.Digital timers are ideally suited for applications where highest degree of accuracy in time setting is a must.Its quartz crystal time based circuit guarantee 0.01% accuracy for precision operations.
- On energisation ,the timer displays the time set on the thumb wheel switch and starts down/up counting.
- Timer switches over to delayed change-over contact after the lapse of preset time.
- Timer resets to the initial set position on de-energisation.
- In case of premature interruption in input supply the timer resets to its original set time without actuating the contacts.
- Time Base: Quartz Crystal Base
- Type: On Delay/Off Delay
- Supply Voltage: 230V/110V 50Hz AC, 24V/12V DC (+_15%)
- Time Range : Seconds/Minutes/Hours
- Contacts : 2 Change-over Delayed/Instantaneous
- Rating : 5Amps Resistive Load
- Mounting: Panel Mounting /Wall/Din Rail
- Burden : 2.5 VA
- Reset Time : 10 M.Sec
- Dimensions : 96*96 mm/72*72 mm
- Cut Out Size: 90*90 mm/70*70 mm
- Depth : 120mm/115mm
- Housing : Plastic (ABS)
- Protection Class: IP 44(IS 2147.1962)
- Display : 7 Segment LED Display
- Time Setting : Thumb Wheel Switch
- Ambient Temp : Upto 45 C
- Non-Standard ranges available at extra cost
- Blind Timers without display available.
